Flynbuicks 70 GSX STG 1 4spd in pictures

Discussion in 'Chassis restoration' started by Jim Weise, Nov 15, 2006.

  1. Jim Weise

    Jim Weise EFI/DIS 482

    Hi guys,

    My time is a bit limited tonight by other demands, but I do have the pictures available now of Jim's X. I will try and post a few new ones each day here.

    Thx.

    JW


    Attached Files:

  2. Jim Weise

    Jim Weise EFI/DIS 482

    As we go thru, I will point out a few things..

    We were lucky to have the original grill that this 49K mile car came with, and a few things are important to note:

    1. Molded in Gray Plastic
    2. The top of the grill is actually not painted argent silver. It's just the natural gray plastic.

    We did have to refinish the Argent Silver, but the black paint on the center bar, as well as on the dark gray on the eggshells was painted by the boys in Flint, nearly 37 years ago.

    It was an amazingly well preserved piece.


    Attached Files:

  3. NSBound

    NSBound Well-Known Member

    Looking forward to the pics!

    Hi Jim, I am sure I speak for many regulars on here when I saw we're all looking forward to seeing the pictures as they get posted. Thanks for taking the time! And nice pics so far! :beer

  4. Jim Weise

    Jim Weise EFI/DIS 482

    Evident here is the original GSX headlight bezel (refinished of course) the T-3 reproduction headlamps, and a look at paint finish, and the front of the stripes.

    Keep in mind this car is painted in Glasurite Basecoat/Clearcoat. With the proper amount of after paint sanding and buffing work, it's difficult to determine that it is not painted in lacquer.

    Nearly as much time was spent finishing the paint, and striping this car, as was spent straightening and prepping, and painting it Saturn Yellow.

    We had the BASF/Glasurite lab in Germany actually formulate the color, based on an original GSX panel, to match the paint as accurately as possible.

    For those of you with a Yellow X who wish to use this paint, I would gladly send you a copy of the forumla. While the Glasurite clear/hardener and basecoat reducers are aproximately 1/3 more expensive than the top line products of other manufacturers, the actual yellow was fairly competative at $450 a gallon. It took 1 gallon of high hiding white as the ground coat, and 2 complete gallons of Saturn Yellow to paint this car. Coverage is excellent with 4 coats, and those of you who have painted a yellow car can attest that since it is translucent, this can be an issue. Glasurite base is only reduced 50%, vs the 100% reduction of most other bases. This certainly helps the coverage issue.

    If your considering using this paint in your restoration, be advised that it is absolutely critical to use the Glasurite clearcoat, as it has a bit of a yellow tint to it, caused by the components that make up the UV protection package of the clear. The base was forumlated with this in mind, so the use of another clear may result in too light a yellow.


    Attached Files:

  5. Stage1 Jeff

    Stage1 Jeff Guest

    nice car! the '70 QQ stage1 GSX has always been my dream car.( anyone wanna give one to me?? :) )
    I have always wondered what it costs to restore one to concours condition??
    and do they also try to reproduce the color code stripes on the vacuum hoses?

  6. Jim Weise

    Jim Weise EFI/DIS 482

    A few things here:

    Correct PN and date coded Alternator, restored by Ken Bruno who does a fantastic job. Phosphate adjuster bracket. The orginal fan shroud, cowl top and hose hook are in place and in perfect condition.

    The scoop foam seals are another interesting story. Unlike later model GM foams, these are the same vintage as the car.. I call them "old new old stock". While later model foams came packed in a smaller box, these actually came in about a 6x6 box, and still had the center part of the foam in them. They were actually just die cut, and them placed in the box. That center piece held the shape of the foam seal perfectly, and they are just sitting on this air cleaner, not glued down.

    As you all know, finding GM 455 foam seals these days is difficult, finding a set of these with the foam still in the middle, that someone will actually sell you, is virtually impossible. They don't call Jim the "Parts Ferret" for nothing.. :eek2:

    Definately as authentic as you can get.

    That's all for tonight, as I have some other business to attend to. We will pick this up Friday night again..


    Attached Files:

  7. flynbuick

    flynbuick Guest


    Last edited by a moderator: Nov 19, 2006
  8. Stage1 Jeff

    Stage1 Jeff Guest

    I didn't know that, thanks Jim,and enjoy your car!!

  9. GStage1

    GStage1 Always looking for parts!

    Hmmmmmmmmm, I think JW got a new girlfriend or has a super-hot date tonight! Congrats! :beer :beer :beer

  10. Dana/Beth Andrews

    Dana/Beth Andrews Huc accedit zambonis!


    Either that or he has to take BudDog out for another one of his (BudDog's) hour long peeeeeeeeeee's... :rolleyes:

    Nice pictures, thanks for posting them.

    Beth :grin:

  11. Jim Weise

    Jim Weise EFI/DIS 482


    :rolleyes:



    Don't confuse my life with your hula girl chasing antics there Sunshine boy.. :grin: :laugh:

    Just sittin' here doing resto estimates..


    And bud-dog is passed out on the sofa.

  12. ToddsGS

    ToddsGS Founders Club Member

    Jim L. Beautiful Car!

    Jim W. Fantastic Work!

    Can't wait to see more Pics! ! ! !


    By the way, great car for a company mascot! ! !
    .


    [​IMG]

  13. JOE RIV 1

    JOE RIV 1 Well-Known Member

  14. UnseenGSX

    UnseenGSX Well-Known Member

    Very nice Car can't wait to see it Jim. I'm sure you are going to take it to BG. If every thing goes right maybe I will have mine there as well.

  15. 68 Skylark cust

    68 Skylark cust French Canadian Member

    If you do so you'll need to change your user name ! :pp


    That is going to be a very nice GSX , always interesting to watch . Congrats to both of Jims :TU:

  16. Steve Schlater

    Steve Schlater Well-Known Member

    Keep The Pictures Coming....

    Congrats to both of you......What an awesome piece of history that you guys just restored. :TU:

  17. Speedy

    Speedy Well-Known Member

    The foam on original ram air seals should be yellow. Those are repos. :(

  18. bostongsx

    bostongsx Platinum Level Contributor

    Nice job trishield :TU:

  19. copperheadgs1

    copperheadgs1 copperheadgs1

    Everyone almost uses repro hood foams. Not many options any more. There are some good ones out there now with nice corners. Just got some just color is not quite right but best available. By NOS and just crush them with the hood anyway. Awesome looking car by the way.

  20. UnseenGSX

    UnseenGSX Well-Known Member

    I just don't know what I will use but in time it will come to me.
