D&S Performance Buick 455/462 V8

Discussion in 'V-8 Buick Powered Regals' started by STAGE-2 TORQUE, Sep 20, 2009.

  1. rkammer

    rkammer '71 GS455 Arctic White

    Understand. Isn't the MSD 6AL rev limiter user adjustable? I thought it was but could be wrong.

    STAGE-2 TORQUE likes this.
  2. STAGE-2 TORQUE

    STAGE-2 TORQUE STAGE-2 Buick "482 Stroker"

    ... it is adjustable. The plastic dial (tiny flat head screw driver supplied with the MSD-6AL-2 box. The 1000-increment dial, is deformed ... and is stuck @ 4400-rpm Rev-Limit.

    :)

  3. STAGE-2 TORQUE

    STAGE-2 TORQUE STAGE-2 Buick "482 Stroker"

    ... guess WHAT my Lifter Noise is from???


    o_O:eek::confused::(:D




    :oops::oops::oops:

  4. STAGE-2 TORQUE

    STAGE-2 TORQUE STAGE-2 Buick "482 Stroker"

    Good morning, ALL.
    This is the 1st time I drove my Buick on a highway against another vehicle;






    Since the new Jim Weise 3000-3200 stall torque converter ... my Buick runs HARD. The new Max Air Carbs Holley-950 works GREAT as well.

  5. STAGE-2 TORQUE

    STAGE-2 TORQUE STAGE-2 Buick "482 Stroker"




  6. STAGE-2 TORQUE

    STAGE-2 TORQUE STAGE-2 Buick "482 Stroker"



  7. rkammer

    rkammer '71 GS455 Arctic White

    Watched the video and didn't see any competitive driving???

    STAGE-2 TORQUE likes this.
  8. TrunkMonkey

    TrunkMonkey Well-Known Member

    That's because the camera is facing forward... :p

    STAGE-2 TORQUE likes this.
  9. STAGE-2 TORQUE

    STAGE-2 TORQUE STAGE-2 Buick "482 Stroker"


    :D

  10. STAGE-2 TORQUE

    STAGE-2 TORQUE STAGE-2 Buick "482 Stroker"

    Good night, ALL. This is a video clip you'll LOVE; I feel. :D




  11. STAGE-2 TORQUE

    STAGE-2 TORQUE STAGE-2 Buick "482 Stroker"

  12. hugger

    hugger Well-Known Member

    Dude that converter appears to be way to far out from the pump

  13. TrunkMonkey

    TrunkMonkey Well-Known Member

  14. STAGE-2 TORQUE

    STAGE-2 TORQUE STAGE-2 Buick "482 Stroker"

    Good morning ALL.



    Have a great week ahead.

  15. STAGE-2 TORQUE

    STAGE-2 TORQUE STAGE-2 Buick "482 Stroker"

    Good morning.

    I really appreciate your comment ... I got very concerned, and did a little research; and found this so far ... :eek:




    I'm going to call my Tranny-Builder.

  16. STAGE-2 TORQUE

    STAGE-2 TORQUE STAGE-2 Buick "482 Stroker"



    This is my converter. I'm going to call Jim Weise and ask for the Input Shaft's length ... and if he feels it's too far out. Thanks again.

    :)

    BUICK 455 Jim Wiese 3000-3200-stall TH400 converter -d (2).jpg

  17. STAGE-2 TORQUE

    STAGE-2 TORQUE STAGE-2 Buick "482 Stroker"


    My TH400 builder said it's OK, and I shouldn't worry. The Input Shaft on this 9.5-inch Converter is long.
    It's been the same way for a year.

    Thanks VERY much again.

  18. LARRY70GS

    LARRY70GS a.k.a. "THE WIZARD"

    You should be using the washers that Jim supplied. It has nothing to do with the input shaft length. It has to do with the engagement of the pump tabs in the converter snout notches. With the converter pushed all the way into the transmission, there should be 3/16" - 1/4" of clearance. You want to pull the converter forward about 1/8" to mate to the flexplate. That's where the washers come in. You don't need your transmission builder, just unbolt the converter and push it back. You will probably need both washers on each bolt, but you can measure and confirm. If the converter is pulled too far forward, you can damage the pump tangs and or the converter snout because they don't engage fully/properly.

    Last edited: Sep 10, 2018
    STAGE-2 TORQUE likes this.
  19. hugger

    hugger Well-Known Member

    It may have been just the angle in that one shot, but they looked like an awful lot it converter hub showing

    STAGE-2 TORQUE likes this.
  20. STAGE-2 TORQUE

    STAGE-2 TORQUE STAGE-2 Buick "482 Stroker"

    ... I was "dying" for a reply from you. I don't remember receiving any washers ... just the Converter.

    I'll contact Mr. Weise again, and ask for more Washers. He did mention them in a reply earlier.

    Thanks VERY much for confirmation. I hope to see you soon.

    Have a great week ahead. :D:D:D
